3M Scotchcast™ 208 Semiflexible Epoxy Electrical Resin, 8 lb, Reddish-Brown
MFR #:7010401201
EIS #:3MR2088LB
UPC #:00051128613832
MFR #:7010401201
EIS #:3MR2088LB
UPC #:00051128613832
Out of Stock
Min Qty:1
|Qty Increment:1
This is a two-part, room-curing, semi-flexible, unfilled, epoxy liquid resin.
3M™ Scotchcast™ Electrical Resin 208N is a 2 part, liquid resin that is useful for electronic and electrical applications requiring the highest level of protection. This unfilled, epoxy based resin has a good adhesion property, which makes it easy to infuse on any surface. It is useful for applications that include filling, patching, insulating and more
$810.89 / Kit
Min Qty:1
|Qty Increment:1
This is a two-part, room-curing, semi-flexible, unfilled, epoxy liquid resin.
3M™ Scotchcast™ Electrical Resin 208N is a 2 part, liquid resin that is useful for electronic and electrical applications requiring the highest level of protection. This unfilled, epoxy based resin has a good adhesion property, which makes it easy to infuse on any surface. It is useful for applications that include filling, patching, insulating and more
- Attributes
- Features
- Documents
Attributes
General Information
Item NameEpoxy Electrical Resin
Trade NameScotchcast™
SeriesScotchcast™ 208
General Features
TypeSemiflexible
Design & Construction
Base TypeEpoxy
ColorReddish-Brown
Cure TypeRoom Temperature
FormLiquid
Performance Details
Tensile Strength700 psi
Flexural Strength875 psi
Moisture Absorption1.6%
Chemical Properties
Mixing Ratio1:1 (Weight), 46:54 (Volume %)
Specific Gravity1.12
Viscosity7000 cP
Viscosity - Part-A12500 cP
Viscosity - Part-B4000 cP
Electrical Properties
Dielectric Strength325 V/mil
Physical Properties
Container Size8 lb
Container TypeKit
Hardness68 Shore D
Elongation75%
Environmental Condition
Temperature Rating130 °C
Features
- Because of the product`s good wetting and impregnating properties, there is little scrap and little need for rework or patching
- Preferred curing cycle for all frame sizes is 48 hr at room temperature
- 4.4 at 1000 Hz 23 °C dielectric constant
- 0.09 at 1000 Hz 23 °C dissipation factor
- 10^13 ohm-cm at 23 °C volume resistivity
- Gel Time: 30 min at 60 °C (140 °F)
- Flash Point: A = 204 °C/400 °F, B = 201 °C/345 °F
- Viscosity: 7000 CP at 23 °C/73 °F
- Density: A = 1.16 kg/l (9.7 lb/gal), B = 0.995 kg/l (8.3 lb/gal)
- Temperature rating: Class B (<=130 °C)
- Thermal Conductivity: 4.2 x 10^-4 Cal/sec/cm^2/°C/cm
- Viscosity - Part-B: 4000 CP at 23 °C/73 °F
