MFR #:184
EIS #:PH11-184
Series #:184
MFR #:184
EIS #:PH11-184
Series #:184
Dow Corning brand silicone 10 to 1 encapsulants are supplied as two-part liquid component kits. Dow Corning silicone elastomers require no post cure and can be placed in service immediately following the completion of the cure schedule. Standard silicone encapsulants require a surface treatment with a primer in addition to good cleaning for adhesion while primerless silicone encapsulants require only good cleaning. - 2-part, clear, 10:1, RT and heat cure, good strength, UL and Mil Spec, same as Sylgard 182 but with faster RT cure. Sylgard 184 silicone elastomer is suitable for LED lighting encapsulation, industrial controls, high voltage resistor packs.
$229.39
- $1,139.86
Select from the options below
Dow Corning brand silicone 10 to 1 encapsulants are supplied as two-part liquid component kits. Dow Corning silicone elastomers require no post cure and can be placed in service immediately following the completion of the cure schedule. Standard silicone encapsulants require a surface treatment with a primer in addition to good cleaning for adhesion while primerless silicone encapsulants require only good cleaning. - 2-part, clear, 10:1, RT and heat cure, good strength, UL and Mil Spec, same as Sylgard 182 but with faster RT cure. Sylgard 184 silicone elastomer is suitable for LED lighting encapsulation, industrial controls, high voltage resistor packs.
Product Options
Showing 2 out of 2 options
Container Size: 3.9kg | EIS Part #: DC184X3.9KG | $ / Kit | ||
Container Size: 0.5kg | EIS Part #: DC184X0.5KG | $ / Kit |
- Attributes
- Features
- Applications
Attributes
General Information
Item NameSilicone Elastomer
Trade NameSylgard®
Series184
General Features
Shelf Life720 Days
StandardsWEEE/RoHS Compliant
TypeKit
Design & Construction
Cure TypeRoom Temperature/Heat Cure
Color - Part-AColorless
Color - Part-BColorless
Form - Part-ALiquid
Form - Part-BLiquid
Chemical Properties
Composition - Part-ASilicone
Composition - Part-BSilicone Resin
Specific Gravity - Part-A1.03
Viscosity - Part-A5000 cSt
Viscosity - Part-B110 cSt
Physical Properties
Container TypeKit
Hardness43 Shore A
Odor/Scent - Part-ASlight
Odor/Scent - Part-BSlight
Features
- Flowable
- Room temperature and heat cure
- Good dielectric properties
- Rapid, versatile cure processing controlled by temperature
- High transparency allows easy inspection of components
Applications
- For Power Supplies, Connectors, Sensors, Industrial Controls, Transformers, Amplifiers, High Voltage Resistor Packs, Relays, Adhesive/Encapsulant for Solar Cells, Adhesive Handling Beam Lead Integrated Circuits During Processing
