MFR #:5414
EIS #:PH22-5414
MFR #:5414
EIS #:PH22-5414
3M 5414 water soluble wave solder tape has polyvinyl alcohol backing which is water soluble and a synthetic water soluble adhesive. This tape is designed to mask gold fingers on printed circuit boards during wave soldering, no adhesive residue after removal, low static upon liner release and when taping board, humidity extremes do not affect tape properties, used to mask gold fingers on printed circuit boards during wave soldering. - No adhesive residue after removal. Low static upon liner release and when taping board. Moisture barrier packaging plus desiccant. Humidity extremes do not affect tape properties. Easy manual and machine application.
$72.63
- $127.96
Select from the options below
3M 5414 water soluble wave solder tape has polyvinyl alcohol backing which is water soluble and a synthetic water soluble adhesive. This tape is designed to mask gold fingers on printed circuit boards during wave soldering, no adhesive residue after removal, low static upon liner release and when taping board, humidity extremes do not affect tape properties, used to mask gold fingers on printed circuit boards during wave soldering. - No adhesive residue after removal. Low static upon liner release and when taping board. Moisture barrier packaging plus desiccant. Humidity extremes do not affect tape properties. Easy manual and machine application.
Product Options
Showing 4 out of 4 options
Width: 2 Inch | EIS Part #: 3M5414X2 | $ / Roll Pack: 6/Case | ||
Width: 1 Inch | EIS Part #: 3M5414X1 | $ / Roll Pack: 9/Case | ||
Width: 0.75 Inch | EIS Part #: 3M5414X.75 | $ / Roll Pack: 12/Case | ||
Width: 0.5 Inch | EIS Part #: 3M5414X.5 | $ / Roll Pack: 18/Case |
- Attributes
- Applications
Attributes
General Information
Item NameSolder Masking Tape
Series5414
General Features
Shelf Life12 Months
Storage Temperature16 to 27 °C
Design & Construction
Backing MaterialPolyvinyl Alcohol Film
ColorClear
ShapeRoll
Adhesive TypeWater Soluble Synthetic
Performance Details
Tensile Strength6 lb/Inch
Adhesive Strength4 oz/Inch
Physical Properties
Length36 Yard
Thickness2.1 mil
Width0.500 Inch
Core Size3 Inch
Elongation334%
Applications
- For Mask Gold Fingers on Printed Circuit Boards During Wave Soldering
