FEP film is used for applications requiring optical clarity, quick release and abrasion resistance. The FEP backing offers excellent high temperature resistance and offers the highest electrical strength in V/Mil. FEP backing is chemically inert, thin and conformable. - The tape construction is weather resistant, stable and non-toxic. FEP film applications include high temperature coil and capacitor wrapping, composite bonding, masking and conveyor release linings.
$44.14
- $81.87
Select from the options below
FEP film is used for applications requiring optical clarity, quick release and abrasion resistance. The FEP backing offers excellent high temperature resistance and offers the highest electrical strength in V/Mil. FEP backing is chemically inert, thin and conformable. - The tape construction is weather resistant, stable and non-toxic. FEP film applications include high temperature coil and capacitor wrapping, composite bonding, masking and conveyor release linings.
Product Options
Showing 3 out of 3 options
Width: 1 Inch | Core Size: 1 Inch | EIS Part #: OAK2355-2X1 | $ / Roll | ||
Width: 0.75 Inch | Core Size: 3 Inch | EIS Part #: OAK2355-2X.75 | $ / Roll | ||
Width: 0.5 Inch | Core Size: 3 Inch | EIS Part #: OAK2355-2X.5A | $ / Roll |
- Attributes
- Features
- Applications
Attributes
General Information
Item NameTape
Series2355-2
Design & Construction
Backing MaterialFluorinated Ethylene Propylene
ColorClear
Adhesive TypeSilicone
Performance Details
Tensile Strength8 lb/Inch
Adhesive Strength20 oz/Inch
Electrical Properties
Dielectric Strength9000 V
Physical Properties
Length36 Yard
Thickness3.5 mil
Elongation275%
Environmental Condition
ResistsChemical
Temperature Rating400 °F
Features
- 2355-2 tape construction is weather resistant, stable and non-toxic
- Available with or without a liner
- Chemically inert, thin and conformable
- Durable and versatile
- FEP backing offers excellent high temperature resistance
- FEP offers the highest electrical strength in V/Mil
- Temperature rating of -100 to 400 °F
Applications
- For Primary Insulation in Motor Coils, Transformers and other Electrical Components
